Technical data
Laser class 3R, < 2 mW / diode
Laser visible red, 635 nm
Beam diameter
12 mm
Working range up to200 m
Grade range -20 % +40 %
Self-levelling range 5
Minimum display reading 0,001%
Horizontal accuracy 5 mm/100 m
Left / right scanning 4
Operating time 24 h (NiMH)
Temperature range -20 C +50 C
Power supply 4 x D 8000 mAh NiMH
(optional 4 x D Alkaline)
Remote control range
front / back 60 m/10 m
Dust / water protection IP 68
Dimensions 132 mm, length 380 mm
Weight (laser only) 5 kg
Weight set 11 kg
