Technical data
Camera head

Viewable angle 0 and 180
Focal length 6 - 7 cm
Viewable distance 5 - 15 cm
Diameter of camera head 17 mm
Light source LED
Display

Display size 3,2
Resolution 320x 240 pixel
Image transmission to LCD Flexible gooseneck
CMOS Image sensor 300.000 Pixel
Video output (to TV) PAL / NTSC
Picture / video formats JPG / 3 GP
Resolution picture / video
320 x 240 pixel
Various

Internal memory 70 MB
Additional memory
4 GB SD-card
supports up to 8 GB (optional)
Operation languages EN, FR, DE, ES
Probe length 100 cm
Bend radius of probe 6 cm
Dust / water protection probe / camera IP 67
Power supply 3,7V / 2000 mAH Li-Ion
Operating time 4 h
Temperature range -10 C + 50 C
Humidity range 15 85 % RH
Dimensions 240 x 160 x 100 mm
Weight with probe 0,584 kg
