Technical data
Camera head
Viewable angle 0 and 180
Focal length 6 - 7 cm
Viewable distance 5 - 15 cm
Diameter of camera head 17 mm
Light source LED
Display
Display size 3
Resolution 960 x 240 pixel
Image transmission to LCD Flexible gooseneck
CMOS Image sensor 300.000 pixel
Video output (to TV) PAL / NTSC
Various
Probe length 100 cm
Bend radius of probe 6 cm
Dust / water protection probe and camera IP 67
Power supply 3,7V / 2000 mAH Li-Ion
Operating time 4 h
Temperature range -10 C + 50 C
Humidity range 15 85 % RH
Dimensions 240 x 160 x 100 mm
Weight with probe 0,584 kg
